Wireless Digital Pressure Gauge NB IoT 4G Lora Waterproof IP67 Pressure Transmitter

Brand Name:	TOPRIE
Model Number:	TP2401
MOQ:	1 piece
Payment Terms:	MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability:	100 pieces per day

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

CE,ROHS

Document:

Packaging Details:

Packed in paper carton

Supply Ability:

100 pieces per day

Highlight:

Wireless Digital Pressure Gauge NB IoT

4G Lora Pressure Transmitter

Waterproof IP67 Pressure Transmitter

Product Description

Wireless Digital Pressure Gauge NB IoT 4G Lora Waterproof IP67 Pressure Transmitter

TP2401 is a high-performance wireless pressure monitor built for long-distance data collection. Equipped with a heavy-duty IP66 waterproof enclosure, this sensor delivers stable and precise real-time data transmission over LoRaWAN or 4G cellular networks, performing steadily even under severe outdoor industrial conditions. Compatible with the TOPRIE IoT cloud system, this device is perfectly suited for remote pressure tracking across industrial pipelines and environmental engineering projects.

Wireless Digital Pressure Gauge NB IoT 4G Lora Waterproof IP67 Pressure Transmitter 0

Technical Data

WaterProof Wireless Pressure Sensor Parameters
Pressure Sensor Range	0~1.6MPa (default); (-0.1~60MPa optional), Support customize.
Working power	Battery powered explosion-proof version 3.6V, 17Ah (External power supply and rechargeable version need to be specified)
Battery life	LORAWAN/ LoRa communication: 5-6 years (data is uploaded once an hour, with a stable signal);
	4G/WIFI communication: 2-2.5 years (data is uploaded once an hour, with a stable signal);
	Battery model (non-rechargeable batteries, replaceable batteries);
Internal battery	With alarm function of low battery
Protection level	Waterproof model IP66
Display	TFT LCD screen
Power consumption	Standby current ≤80uA, average data transmission current ≤150mA1
Network Standard	WIFI, 4G/GSM(SIM card), LoRa (Need use our LoRa gateway), RS485,LoRaWAN, NB-IOT, RS485, GPRS (optional)
Antenna	External antenna
Installation Orientation	Vertical or Horizontal
Sampling interval	Configurable time is 10S~2550S
Configuration	Configurable time is 1min~1440min. Note: The shorter of configurable time, the shorter usage of battery life
Data transmit interval	USB configuration operation, server remote configuration, Bluetooth configuration
Wake-up mode	Button, timing
Upload information	Pressure, temperature, battery level, signal, card number
Operating temperature	-30°C~70°C (medium does not crystallize)once temp over 70°C, pls tell us.
Humidity	0-100%RH
Overload pressure	200%FS(below 10MPa);150%FS(25MPa)
Sensor material	The sensor housing is made of stainless steel and the pressure diaphragm is 316L
Measurement accuracy	0.5% F.S (default), (0.2%FS, 0.1%FS optional)
Temperature Effect	0.015%F.S/°C
Interface specifications	Thread interface, M20*1.5 (thread can be customized)

Advantages

Automatic pressure data recording and archiving
Long range wireless real-time data transmission
Low power battery power with long service life
Rugged industrial housing for harsh working conditions
Cloud server for data storage and trend analysis
Remote access via mobile APP and web browser

Application

Smart Agriculture, Petroleum pipeline networks, natural gas pipeline networks,Water and Wastewater Management,Oil and Gas Monitoring, Building Management Systems, Fire Systemand other flammable and explosive atmospheres.

FAQ

Q: What is the measurement range of the pressure sensor?

A: The pressure measurement range of the TP2401 is from -0.1 MPa to 100 MPa

Q: What is the measurement accuracy of the pressure sensor?

A: The default pressure measurement accuracy is 0.5% F.S, with optional accuracies of 0.2% F.S and 0.1%F.S

Q: What communication methods does the wireless pressure gauge support?

A: Supports 4G, 5G, Wi-Fi, LoRa, NB-IoT, LoRaWAN, and RS485 communication methods

Q: How long is the battery life of the TP2401?

A: 4G version: 2.5 years (default settings); NB-IoT/LoRa versions: 5 years

Q: What is the protection rating of the TP2401?

A: Waterproof variant: IP66 (general outdoor use); Explosion-proof variant: IP67 (outdoor/underground use)

Q: What is the sampling frequency of the TP2401?

A: Configurable from 10 seconds to 2550 seconds, default 60 seconds

Q: What is the upload frequency of the TP2401?

A: Configurable from 1 minute to 1440 minutes (24 hours), default 60 minutes

Q: What communication protocol is used for the 4G version?

A: Default MQTT protocol, with optional TCP protocol

Note: Real-world battery life may vary based on environmental conditions and configuration settings. Explosion-proof variant certified for hazardous environments including mining operations.
